The Emergence Of A Theme
I’m not sure what it is, but there continues to be some sort of “competition” for “who can find the biggest bug” — as if attackers had to choose, and more importantly, as if any bug was so big that it could not be made even better by combined use with its “competition”. Before my DNS talk, my old friend FX from Recurity Labs was comparing DNS issues to the Debian Non-Random Number Generator issue that caused all sorts of SSL certificates to offer no security value, and the SNMPv3 flaws that allowed infrastructure devices to be remotely administered by people who happened not to know the password.
Of course, after the talk, it became clear that the DNS hack and the Debian NRNG combined rather destructively — DNS allowed you to finally play MITM with all the SSL private keys you could trivially compute, and as Ben Laurie found, this included the keys for Sun’s OpenID authentication provider. And, since the DNS hack turns Java back into a universal UDP and TCP gateway, we end up being able to log into SNMPv3 devices that would otherwise be protected behind firewalls.
So there’s no sense making a competition out of it. There’s just an ever growing toolchest, growing from a single emerging theme:
Weaknesses in authentication and encryption, some which have been known to at least some degree for quite some time and many of which are sourced in the core design of the system, continue to pose a threat to the Internet infrastructure at large, both by corrupting routing, and making those corrupted routes problematic.
Back in July, the genuinely brilliant Halvar Flake posted the following regarding the entire DNS issue:
“I fail to understand the seriousness with which this bug is handled though. Anybody who uses the Internet has to assume that his gateway is owned.”
And thus, why 75% of my Black Hat talk was on the real-world effectiveness of Man-In-The-Middle attacks: Most people aren’t as smart as Halvar. I’m certainly not :) Almost nobody assumes that their gateway is owned — and even those that do, and try to engineer around it, deploy ineffective protections that are only “secure unless there’s an attacker”.
I say this is a theme, because it is the unifying element between some of the year’s most high profile flaws. There are two subclasses — some involve weak authentication migrating traffic from one location to another, while others involve weak authentication allowing an attacker to read or modify traffic migrated to him — but you’d have to have some pretty serious blinders to not see the unifying theme of weak authentication leads to pwnage.
Consider:
Luciano Bello’s Debian NRNG: This involves a core design requiring the generation of random numbers, but the random number generator required a random seed, but alas, the seed was made insufficiently random. It’s an implementation flaw, but barely — and the effect was catastrophic failure against members of the X.509 PKI authentication system that had used the Debian NRNG, and thus by extension SSL’s encryption logic and OpenID (for Sun’s) authentication gateway.
Wes Hardakar’s SNMPv3 Bug: Here, we have an authentication protocol that allows an attacker to declare how many bytes he wants to have to correctly provide. Now, the attacker can claim “just 1 please” — and he gets into any router suffering this bug within seconds. That, by extension, allows control over all traffic traversing that router.
Mike Zusman’s Insecure SSL-VPN’s: SSL is supposed to protect us, but there’s no sense creating a secure session to someone if you don’t actually know who they are. Don’t worry though, by design anything that isn’t a web browser is terrifyingly likely to only to skip authentication entirely and just create an encrypted link to whoever’s responding. One would think that SSL-VPN’s, whose sole purpose is to prevent attackers from accessing network traffic, would be immune. But with 42% of certificates on the Internet being self-signed, and a lot of them being for SSL-VPN’s, one would be wrong. By extension this auth failure exposes all traffic routed over these SSL-VPN’s.
Mike Perry’s Insecure Cookies: This gets interesting. Here we have two different authentication protocols in place — one, from server to client, based on X.509. The other, from client to server, based on a plaintext password (delivered, at least, over an encrypted session authenticated by the server-to-client cert). But to prevent the user from needing to repeatedly type in their plaintext password, a password-equivalent token (or cookie) is handed to the user’s browser, which will be attached to every request within the securely encrypted channel. Unfortunately, it’ll also be attached to every request which does not traverse the securely encrypted channel, because the cookies aren’t marked for secure-only. Once the cookie leaks, of course, it’ll authenticate a bad guy who creates an encrypted session to that server. So by extension bad guys get to play in any number of interesting sites.
My DNS flaw: Here we have a protocol that directly controls routing decisions, ultimately designed to authenticate its messages via a random number between 0 and 65535. Guess the number, and change routing. This was supposed to be OK, because you could only guess a certain number of times per day. There was even an RFC entirely based around this time limit. It turns out there’s a good dozen ways around that limit, allowing anonymous and even almost 100% packet spoofed compromise of routing decisions. This, by extension, allowed exploitation of all traffic that was weakly authenticating.
It’s the same story, again and again. And now, everyone talking about BGP. So lets do the same sort of analysis on BGP:
Kapela and Pilosov’s BGP flaw: In BGP, only the nearest neighbor is authenticated. The concept is that all “members of the club” authenticate all other members, while the actual data they provide and distribute is trusted. If it’s not actually trusted, anyone can hijack traffic from anyone else’s routes.
Pilosov’s done some cool work here. It’s not the sort of devastating surprise some people seem to want it to be. Indeed, that’s what makes it so interesting. BGP was actually supposed to be broken, in this precise manner. Literally, in every day use, any BGP administrator has always had the ability to hijack anyone else’s traffic. Pilosov has a new, even beautiful MITM attack, but as mine was not the first DNS attack, his is not the first BGP MITM. Tales of using BGP to force traffic through a compromised router (possibly compromised through SNMPv3) are legion, and Javascript and the browser DOM blur things pretty fiercely in terms of the relevance of being able to pass through to the legitimate endpoint anyway.
That’s not to take away from the work. It’s an interesting trick. But we need to level set here:
First, if you’re not part of the BGP club, you’re just not running this attack. Pakistan took out YouTube with BGP — but some random kid with the ability to spoof IP packets couldn’t. In other words, we’re just not going to see a Metasploit module anyone can run to complete these sorts of attacks. Now, there are some entertaining combinatorics that could be played — DNS to enable Java’s SNMPv3 access to internal routers at an ISP, and then from that internal router running the sort of BGP tricks Pilosov’s talking about. This goes back to the utter folly of trying to rank these bugs independently from one another. But these sort of combinatorics are at a fundamentally different level than the fire-and-forget antics that DNS allowed, and on a fundamental level, the number of potential attackers (and the number of involved defenders) on BGP is a lot lower.
Second, we have far better logging — and thus accountability — in the BGP realm than we do perhaps for any other protocol on the Internet. Consider the archives at APNIC — yes, that’s route history going back to 1999 — and Renesys has even more. That sort of forensic data is unimaginable for anything else, least of all DNS. BGP may have its fair share of bad actors — consider spammers who advertise temporary ranges in unused space for mail delivery purposes, thus getting around blackholes — but any of the really nasty stuff leaves a paper trail unmatched by any other attack.
Third, BGP is something of a sledgehammer. Yes, you’re grabbing traffic — but your control over exactly what traffic you grab is fairly limited. Contrast that with DNS, which allows astonishingly fine grained targeting over exactly what you grab — indeed, you don’t even need to know in advance what traffic you want. The victim network will simply offer you interesting names, and you get to choose on the fly which ones you’ll take. These names may even be internal names, offering the impossible-with-BGP attack of hijacking traffic between two hosts on the exact same network segment.
Finally, BGP suffers some limitations in visibility. Simply grabbing traffic is nice, but bidirectional flows are better than unidirectional flows, and when you pull something off via DNS, you’re pretty much guaranteed to grab all the traffic from that TCP session even if you stop any further poisoning attempts. Contrast that with BGP, which operates at Layer 3 and thus may cause the IP packets to reroute at any point when the TCP socket is still active.
So, does that mean its always better to attack DNS than BGP? Oh, you competitive people would like things to be so simple, wouldn’t you
Pilosov and I talked for about a half hour at Defcon, and I’ve got nothing but respect for his work. Lets look at the other side of things for a moment. First, BGP controls how you route to your name server — if not your recursive server, which may be inside your organization and thus immune to exterior routing protocol attack, then the authoritative servers your recursive servers depend on. Something like this actually happened recently — witness the curious case of the Unauthorized L Roots, and note the astonishingly familiar potential attacks being described. Yes, that’s precisely the scenario of BGP used to hijack root DNS servers — with such hijacking actually being noticed.
More importantly, much of my talk, in which I discuss the impacts of MITM attacks, applies to Kapela and Pilosov’s work as well. It’s 2008, we still don’t have secure email, and that’s just as much of a problem in the face of BGP attacks as it is in the face of DNS attacks.
So, in summary, it’s an interesting side discussion regarding the similarities, differences, and overlaps between DNS and BGP attacks. BGP has far fewer potential attackers, fewer necessary defenders, is a much less agile attack, and is way easier to monitor forensically (and indeed, with companies like Renesys, is being monitored forensically). But so what? It can work, and when it does, it can do much of the same damage we were afraid of via DNS.
We have now had three attacks, in one year, that underscore the fundamentally untrustworthy nature of routing. DNS, BGP, and SNMPv3 all underscore the fact that the network should only be trusted as a best-effort data transmission system — that if you want to make sure everything’s OK, you can’t just assume — you need to cryptographically authenticate, you need to cryptographically encrypt, and you need to do these things to a level of security beyond “secure unless there’s an attacker.”
A lot of us — myself included, when I first started really looking at SSL — thought we were already distrusting the network. We weren’t. That’s what Mike Perry’s telling us, that’s what Mike Zusman’s telling us, and that’s what I’m telling you.
There are some real discussions to be had. It’s 2008. Where’s secure email? Why is almost every autoupdater not from Microsoft thoroughly broken? What is going on with non-browser network clients that can’t handle traffic from an untrusted server? How are we going to migrate the web, and indeed all commercial network activity, to authenticated and encrypted protocols that respect the fundamentally untrustworthy nature of the network?
DNS vs. BGP vs. SNMPv3 is inside baseball. The reality is as follows:
Weaknesses in authentication and encryption, some which have been known to at least some degree for quite some time and many of which are sourced in the core design of the system, continue to pose a threat to the Internet infrastructure at large, both by corrupting routing, and making those corrupted routes problematic.
The question is what to do about it.
(That all being said, I’ll be writing shortly with an update on defenses against DNS. There be news.)
My (Not So) Little Pwnie
Experimental Mail Server Analyzer Online
I’ve modified the test scripts slightly, to allow arbitrary triggering agents (such as a mail server) to report back the quality of their DNS queries. You may very well be surprised what NS’s your mail servers are configured to use. More often than you’d think, people just don’t know.
SIGGRAPH 2008: The Quest for More Pixels
So, last week, I had the pleasure of being stabbed, scanned, physically simulated, and synthetically defocused. Clearly, I must have been at SIGGRAPH 2008, the world’s biggest computer graphics conference. While it usually conflicts with Black Hat, this year I actually got to stop by, though a bit of a cold kept me from enjoying as much of it as I’d have liked. Still, I did get to walk the exhibition floor, and the papers (and videos) are all online, so I do get to write this (blissfully DNS and security unrelated) report.
SIGGRAPH brings in tech demos from around the world every year, and this year was no exception. Various forms of haptic simulation (remember force feedback?) were on display. Thus far, the best haptic simulation I’d experienced was a robot arm that could “feel” like it was actually 3 pounds or 30 pounds. This year had a couple of really awesome entrants. By far the best was Butterfly Haptics’ Maglev system, which somehow managed to create a small vertical “puck” inside a bowl that would react, instantaneously, to arbitrary magnetic forces and barriers. They actually had two of these puck-bowls side by side, hooked up to an OpenGL physics simulation. The two pucks, in your hand, became rigid platforms in something of a polygon playground. Anything you bumped into, you could feel, anything you lifted, would have weight. Believe it or not, it actually worked, far better than it had any right to. Most impressively, if you pushed your in-world platforms against eachother, you directly felt the force from each hand on the other, as if there was a real-world rod connecting the two. Lighten up a bit on the right hand, and the left wouldn’t get pushed quite so hard. Everything else was impressive but this was the first haptic simulation I’ve ever seen that tricked my senses into perceiving a physical relationship in the real world. Cool!
Also fun: This hack with ultrasonic transmitters by Takayuki Iwamoto et al, which was actually able to create free-standing regions of turbulence in air via ultrasonic interference. It really just feels like a bit of vibrating wind (just?), but it’s one step closer to that holy grail of display technology, Princess Leia.
Best cheap trick award goes to the Superimposing Dynamic Range (YouTube) guys. There’s just an absurd amount of work going into High Dynamic Range image capture and display, which can handle the full range of light intensities the human eye is able to process. People have also been having lots of fun projecting images, using a camera to see what was projected, and then altering the projection based on that. These guys went ahead and, instead of mixing a projector with a camera, they mixed it with a printer. Paper is very reflective, but printer toner is very much not, so they created a shared display out of a laser printout and its actively displayed image. I saw the effects on an X-Ray — pretty convincing, I have to say. Don’t expect animation anytime soon though (Side note: I did ask them about e-paper. They tried it — said it was OK, but not that much contrast.)
Always cool: Seeing your favorite talks productized. One of my favorite talks in previous years was out of Stanford — Synthetic Aperture Confocal Imaging. Unifying the output of dozens of cheap little Quickcams, these guys actually pulled together everything from Matrix-style bullet time to the ability to refocus images — to the point of being able to see “around” occluding objects. So of course Point Grey Research, makers of all sorts of awesome camera equipment, had to put together a 5×5 array of cameras and hook ‘em up over PCI express. Oh, and implement the Synthetic Aperture refocusing code, in realtime, demo’d at their booth, controlled with a Wii controller. Completely awesome.
Of course, some of the coolest stuff at SIGGRAPH is reserved for full conference attendees, in the papers section. One nice thing they do at SIGGRAPH however is ask everyone to create five minute videos of their research. This makes a lot of sense when what everyone’s researching is, almost by definition, visually compelling. So, every year, I make my way to Ke-Sen Huang’s collection of SIGGRAPH papers and take a look at the latest coming out of SIGGRAPH. Now, I have my own biases: I’ve never been much of a 3D modeler, but I started out doing a decent amount of work in Photoshop. So I’ve got a real thing for image based rendering, or graphics technologies that process pixels rather than triangles. Luckily, SIGGRAPH had a lot for me this year.
First off, the approach from Photosynth continues to yield Awesome. Dubbed “Photo Tourism” by Noah Snavely et al, this is the concept that we can take individual images from many, many different cameras, unify them into a single three dimensional space, and allow seamless exploration. After having far too much fun with a simple search for “Notre Dame” in Flickr last year, this year they add full support for panning and rotating around an object of interest. Beautiful work — I can’t wait to see this UI applied to the various street-level photo datasets captured via spherical cameras.
Speaking of cameras, now that the high end of photography is almost universally digital, people are starting to do some really strange things to camera equipment. Chia-Kai Liang et al’s Programmable Aperture Photography allows for complex apertures to be synthesized above and beyond just an open and shut circle, and Ramesh Raskar et al’s Glare Aware Photography evaded the megapixel race by filtering light by incident angle — a useful thing to do if you’re looking to filter glare that’s coming from inside your lens.
Another approach is also doing well: Shai Avidan and Ariel Shamir’s work on Seam Carving. Most people probably don’t remember, but when movies first started getting converted for home use, there was a fairly huge debate over what to do about the fact that movies are much wider (85% wider) than they are tall. None of the three solutions — Letterboxing (black bars on the top and bottom, to make everything fit), Pan and Scan (picking the “most interesting” square of video from the rectangular frame), or “Anamorphic” (just stretch everything) — made everyone happy, but Letterboxing eventually won. I wonder what would have happened if this approach was around. Basically, Avidan and Shamir find the “least energetic” line of pixels to either add or remove. Last year, they did this to photos. This year, they come out with Improved Seam Carving for Video Retargeting. The results are spookily awesome.
Speaking of spooky: Data-Driven Enhancement of Facial Attractiveness. Sure, everything you see is photoshopped, but it’s pretty astonishing to see this automated. I wonder if this is going to follow the same path as Seam Carving, i.e. photo today, video tomorrow.
Indeed, there’s something of a theme going on here, with video becoming inexorably easier and easier to manipulate in a photorealistic manner. One of my favorite new tricks out of SIGGRAPH this year goes by the name of Unwrap Mosaics. The work of Microsoft’s Pushmeet Kohli, this is nothing less than the beginning of Photoshop’s applicability to video — and not just simple scenes, but real, dynamic, even three dimensional motion. Stunning work here.
It’s not all about pixels though. A really fun paper called Automated Generation of Interactive 3D Exploded View Diagrams showed up this year, and it’s all about allowing complex models of real world objects to be comprehended in their full context. It’s almost more UI than graphics — but whatever it is, it’s quite cool. I especially liked the moment they’re like — heh, lets see if this works on a medical model! Yup, works there too.
As mentioned earlier, the SIGGRAPH floor was full of various devices that could assemble a 3D model (or at least a point cloud) of any small object they might get pointed at. (For the record, my left hand looks great in silver triangles.) Invariably, these devices work like a sort of hyperactive barcode scanner, monitoring how long it takes for the red beam to return to a photodiode. But here’s an interesting question: How do you scan something that’s semi-transparent? Suddenly you can’t really trust all those reflections, can you? Clearly, the answer is to submerge your object in fluorescent liquid and scan it with a laser tuned to a frequency that’ll make its surroundings glow. Clearly. Flurorescent Immersion Range Scanning, by Matthias Hullin and crew from UBC, is quite a stunt.
So you might have heard that video cards can do more than just push pretty pictures. Now that Moore’s Law is dead (how long have we been stuck with 2Ghz processors?), improvements in computational performance have had to come from fundamentally redesigning how we process data. GPU’s have been one of a couple of players (along with massive multicore x86 and FPGA’s) in this redesign. Achieving greater than 50x speed improvements over traditional CPU’s on non-graphics tasks like, say, cracking MD5 passwords, they’re doing OK in this particular race. Right now, the great limiter remains the difficulty programming the GPU’s — and, every month, something new comes to make this easier. This year, we get Qiming Hiu et al’s BSGP: Bulk-Synchronous GPU Programming. Note the pride they have with their X3D parser — it’s not just about trivial algorithms anymore. (Of course, now I wonder when hacking GPU parsers will be a Black Hat talk. Short answer: Probably not very long.)
Finally, for sheer brainmelt, Towards Passive 6D Reflectance Field Displays by Martin Fuchs et al is just weird. They’ve made a display that’s view dependent — OK, well, lenticular displays will show you different things from different angles. Yeah, but this display is also illumination dependent — meaning, it shows you different things based on lighting. There’s no electronics in this material, but it’ll always show you the right image with the right lighting to match the environment. Weird.
All in all, a wonderfully inspiring SIGGRAPH. After being so immersed in breaking things, it’s always fun to play with awesome things being built.
On The Flip Side
What was once possible via 32,769 packets, is still possible via between 134,217,728 and 4,294,967,296 packets. Yep. We’ve been saying that for a while now. So has PowerDNS. So has DJBDNS. There’s nothing specific to BIND here, though I think most people understand that.
What’s going on here is a simple question: Which would you rather build secondary layers of defense against? Thousands of packet? Or billions of packets?
Look. We were looking at an attack before the patch that took ten seconds and was relatively invisible. Four billion packets are many things, but subtle is not one of them.
So there’s a reason you’re not hearing anyone saying, “don’t patch.” And there’s a reason we’ve been telling everyone this is just a stopgap — that we’re still in trouble with DNS, just less. But in business, we choose our risks every single day. That’s why it’s called risk management, not risk elimination.
And for the most part, people seem to get it. Even the story I was somewhat worried about when I’d heard about it — John Markoff’s piece in the New York Times — is a remarkably fair treatment of the issue. Back in March, we needed to come up with a solution to this problem, that could viably protect as many people as possible in a short period of time. DNSSEC has been in progress for nine years. Asking people to deploy it over the course of a month would not have been a pragmatic approach.
DNSSec may be the long term fix. It certainly was not the short term fix.
But can we do better than source port randomization? Possibly. Now comes the wild arguments about what we should really do, to fix this issue. That’s fine by me. That was the idea. But nobody should ever think that they have the One True Fix. I’ve been out here arguing against the 65536-to-1 lottery that fixed source port DNS is. That’s not to say I haven’t been analyzing all the other designs too — but I have to prioritize on things that are in the field, putting customers at risk. I think I’ve argued pretty persuasively that there’s no way 65536-to-1 can ever again offer a sufficient level of security. I don’t know if anyone disagrees with that.
I’m looking forward to better options than source port randomization, even if it means we’ll accept the occasional Gig-E local LAN desktop flood attack hitting our 131M-to-1 to 2B-to-1 mitigations.
It’s the call DJB made all those years ago. It was the right call to make.
Now, lets talk about how entertaining a problem this is going to be to solved, to any degree past what DJB accomplished back in 1999. Note, I’m not saying any final solution won’t use elements of everything that’s about to follow. I’m just saying there are awesomely nasty attacks against everything, and people shouldn’t presume I or others won’t poke sucking chest wounds into seemingly elegant solutions.
First, the universal constraint on every solution is that it must cover the root servers, and the TLD’s, because they’re almost always a better target for poisoning since their position higher in the DNS heirarchy allows them to pollute any name below them. In other words, you can totally opt foo.com into whatever security system you like, but unless A.GTLD-SERVERS.NET (the server for com) is itself secure — and unless the root servers that tell you where A.GTLD-SERVERS.NET — are also included in the solution — there’s no effective security whatsoever. DNSSec, minus the DLV hack, suffers this specific issue, and so does everything else. You either need to be backward compatible all the way up the heirarchy, a trait that port randomization and some other solutions have, or you need to push code to them.
It’s not an impossible proposition to get the root and TLD servers to modify their infrastructure. But that’s not the sort of thing you can make happen via a secret meeting at Microsoft :) It’s a definite negative if they have to change anything.
One solution I’ve sort of liked, believe it or not, is the 0×20 proposal. Basically, this idea from (I think) David Dagon and Paul Vixie notices that DNS is case insensitive (lower case is equal to upper case) but case preserving (a response contains the same caps as a request). So, we can get extra bits of entropy based on asking for wWw.DOXpaRA.cOM, and ignoring replies containing www.DOXPARA.com, WWW.doxpara.COM, etc. 0×20 has some notable corner cases, though — the shorter the domain, the less security can be guaranteed. This is particularly problematic if you’re attacking the roots or TLD’s — especially considering the ability to have almost 100% numeric names, like:
1.a11111111
1.a11111112
1.a11111113
1.a11111114
1.a11111115
Another path that’s suggested is to double query — “debounce”, as one engineer suggested. Debouncing is similar to the “run all DNS traffic over TCP” approach — seems good, up until the moment you realize you’d kill DNS dead. There’s a certain amount of spare capacity in the DNS system — but it is finite, and it is stressed. Absolutely there’s not enough to handle a 100% increase in traffic over the course of a month.
Now raised is the possibility of “attack modes” — large scale state transitions during periods where the server recognizes (it’s not exactly subtle) that it’s under attack. These have a lot of potential, except for the reality that it creates something of a super amplification attack: An attack invests a small number of packets to push every name server on the net into attack mode, and the DNS infrastructure implodes.
Those wouldn’t be very good headlines.
That’s not to say there aren’t more targeted mitigations — this is the sort of work Nominum has been doing with their server, to attempt to prevent individual targeted names from being poisoned. The problem here is how as soon as the attack mode isn’t global, it becomes interesting for the attacker to repeatedly migrate out of the small range that’s in “lockdown” into a new target range.
And there are so many ranges. There’s dozens of variations on the attacks I’m presenting here. For just one example, I may have shown off how to attack www.foo.com via 83.foo.com, but that doesn’t mean it’s not useful to just attack 83.foo.com. The web security model, to varying degrees, trusts arbitrary subdomains as elements of their parents. This was ultimately how I was able to rickroll the Internet at Toorcon.
All the rate limiting approaches have issues with attacks outside the limited range — with the added bonus that somebody’s not getting a reply, a nasty trait that makes attacks on downstream customers of data much more feasible.
Eventually, people realize we could use a better source of entropy — perhaps a prefix on each query name (XQID) or an extra RR (resource record) containing a cookie. Now we need cooperation from the authoritative side of the DNS house. This is tricky, precisely because while it’s one thing to be proud of “+50% of the net has patched”, it’s quite another to say “well you can reach half the domains out there…” The solutions I’ve seen do all have a story for backwards compatibility, storing/caching whether a given name server does or doesn’t support their particular variant.
But again, if the root servers, or the com servers, are not signed up for this system, there’s no incremental benefit to it: The attacker can prevent your nice and secure name server from ever being used by other resolvers in the first place.
And so, we end up at cryptography. DNSSEC is one approach. I don’t think I need to go into the pragmatic, political issues that have made this an issue. From an engineering standpoint though, if we don’t have the headroom for TCP, do we really have the headroom for any cryptography though? Maybe. DNSSEC is not the only possible trick either. Link-based crypto, either via DTLS (keyed via the existing PKI, using the NS name as the Subject) or some TKEY/TSIG dance, could also work.
So, there’s lots of options. Lots, and lots, and lots of options. But, throughout this entire process of analysis, one thing was very clear:
DJB was right. Almost every attack we find, is strongly mitigated by source port randomization. Mitigated, not eliminated, but mitigated just the same. He may not have known how exactly to break BIND or MSDNS in 10 seconds in the real world — frankly, if he did, he’d have told us. But he knew there had to be a way, as Hans Dobbertin knew in 1996 that eventually somebody was going to break MD5. When Wang finally came out with her MD5 collisions in 2004, it wasn’t a surprise — MD5 had been federally decertified for years. But it was still a pretty big deal, since certifications aside MD5 is everywhere.
Fixed source port DNS was everywhere. Less so now. I’m indescribably amazed and honored by that. That’s a lot of hours by a lot of IT guys we’re looking at here. I’m sure there are some pretty happy pizza shops right now. But lets be clear — there are bad guys in the field, and they are using this attack in interesting ways. People who are patched are much, much safer than people who are not.
Finally, as important a question as “how should DNS really be fixed” is, I think the real question of the day is “why does DNS matter so much?”. From Halvar Flake’s first post — “What, doesn’t everyone assume their gateway is owned, and thus use SSL/SSH?” — the underlying instability is the continuing assumption that there is a difference between networks that are hostile and networks that are safe. DNS is a great way to exploit that delusion — especially behind firewalls — but SNMPv3 and BGP both enable all the attacks I’ve found here. Even if we go from 32 bits of entropy to 128 bits — even if we deploy DNSSec — we’re still going to deliver email insecurely. We’re still going to have an almost entirely unauthenticated web. We’re still going to ignore SSL certificate errors, and we’re still going to have application after application that can’t autoupdate securely.
That, at the end of the day, is a far larger problem than this particular DNS issue.
Summaries
Very nice summary of the “How” part of my talk here.
I do think “Why does DNS matter this much?” is a more important question. It’s 2008 — why can I still not email securely between companies? It’s a little sad that such a simple and basic bug can:
1) Break past most username/password prompts on websites, no matter how the site is built.
2) Break the Certificate Authority system used by SSL, because Domain Validation sends an email and email is insecure.
3) Expose the traffic of SSL VPNs, because heh, who needs to check certificates anyway
4) Force malicious automatic updates to be accepted
5) Cause millions of lines of totally unfuzzed network code to be exposed to attack
6) Leak TCP and UDP connectivity behind the firewall, to any website, in an attack we thought we already fixed twice now
7) Expose the traffic of tools that aren’t even pretending to be secure, because “it’s behind the firewall” or “protected by a split-tunneling IPsec VPN”.
It’s just DNS cache poisoning. Why does it get to do this much damage?
The whole “hostile vs. safe” network myth needs to die. Every network is hostile — the DNS bug just made true something that should already have been assumed, but wasn’t. And we need to get faster and better at fixing the infrastructure. Using things until the moment of catastrophic failure — be they bridges, DNS, or MD5 — is a problem, and we can do better.
FX of Phenoelit made an important point a while back — everything you can do with this DNS attack, you can do with SNMPv3. If you haven’t patched your routers — and that includes your internal routers, since Java’s giving UDP access out and you can thus issue SNMP queries with it (not their fault, the entire web security model collapses when DNS is broken and this is just yet another break) — you should probably do that too.
It’s going to be an interesting couple of months. We’re going to see a lot of blended/combination attacks, as attacks we thought were infeasible in the real world suddenly start proving themselves entirely viable (at least, given insecure infrastructure). The previously unfuzzed network clients are probably going to be particularly problematic – if you write a network app that is not a web browser, now is a good time to start feeding random (or even better, semi-random) data to it and switching the autoupdater to SSL. New attacks are already popping up, only a few days in. Ben Laurie just came out with a harrowing and beautiful advisory against some common OpenID deployments. I knew about the intersection of DNS and OpenID, and I knew about the intersection of DNS and Debian’s badly generated certs (a problem which, I’d like to point out, is much harder to patch due to our continuing lack of an effective certificate revocation infrastructure). But it took Ben Laurie to attack “Secure” OpenID providers using Debian Certs via DNS. Fantastic, excellent work.
Best Thing Ever
Fake Dan Kaminsky is the best thing evar. Mad bonus points for the Root Server Gas Pump. I can’t even wrap my mind around how many shots I owe my crew right about now.
Pretty Pictures
Wow, this is pretty cool :) Post in comments if I should throw on the HD version.
Red — Unpatched
Yellow — Patched, but the NAT is screwing things up
Green — OK
(Update: HD Version, thanks to Clarified Networks!)
Why So Serious
Slides. Summary:
• DNS servers had a core bug, that allows arbitrary cache poisoning
– The bug works even when the host is behind a firewall
– There are enough variants of the bug that we needed a stopgap before working on something more complete
• Industry rallied pretty ridiculously to do something about this, with hundreds of milllions protected
• DNS clients are at risk, in certain circumstances
• We are entering (or, perhaps, holding back a little longer) a third age of security research, where all networked apps are “fair game”
– Autoupdate in particular is a mess, broken by design (except for Microsoft)
• SSL is not the panacea it would seem to be
– In fact, SSL certs are themselves dependent on DNS
• DNS bugs ended up creating something of a “skeleton key” across almost all major websites, despite independent implementations
• Internal networks are not at all safe, both from the effects of Java, and from the fact that internal routing could be influenced by external activity
– The whole concept of the fully internal network may be broken – there are just so many business relationships – and, between IPsec not triggering and SSL not being cert-validated, these relationships may not be secure
– We’re not even populating CDN’s securely!
Animation soon.
Black Hat 2008
Five more days until three more conferences.
Three?
Yep — SIGGRAPH finally deigned to not conflict with Black Hat this year, which means I get to stage a return trip to LA and see pretty pictures. I probably won’t end up with a conference pass, but Emerging Technologies is worth the entire trip. So much awesome stuff to play with!
So, everyone’s making lists of stuff they want to see. Here’s some stuff I haven’t heard people talking about:
Concurrency Attacks in Web Applications — Scott Stender
Anyone ever notice how none of the scripting languges have decent threading support — not Perl, not Python, not PHP, not anything? No? It’s because maintaining concurrent access to shared resources is really, really hard — one of the hardest problems in computer science. Theoretically, the problem shouldn’t affect the web, because HTTP is “stateless”.
Well, what’s the first thing every Web Application Framework adds? State. And is concurrent access required to this state?
Not usually…users just have a single browser window open…so, it works! Ship it!
Long term, I suspect Scott’s talk here has significant potential to change web application auditing.
Circumventing Automated JavaScript Analysis Tools — Billy Hoffman
Mobile code happened, and its name is Javascript. I was recently told of a 75K medical management application, written in JS. I refused to believe it until I realized that it probably was faster, and more stable, and written at less cost even, than the same code would have been in any other language.
C++ objects, scripted with a language that won’t usually crash — the only way to write a GUI.
It’s even a lot more secure than it gets credit for. Really, which would you rather parse:
1. x86
2. Java Bytecode
3. MSIL
4. JavaScript
Sure, you can import all sorts of crazy things into the sandbox, but the sandbox itself is pretty good.
Just don’t try to build another sandbox, a second sandbox, out of the sand inside. People want to do this — they want to let this Javascript run, but not that Javascript run, based on prior analysis. This, of couse, will not work. We know it will not work. Turing Completeness and the Halting Problem pretty much delare you hosed. But people try anyway, and now, oh look, it’s Billy Hoffman, standing by a fire truck, turning a valve…
Visual Forensic Analysis and Reverse Engineering of Binary Data — Greg Conti, Erik Dean.
The problem with visualization is simple: 99% of it is crap. 1% of it is so amazingly good, it makes the other 99% worth digging through. Greg’s been working on security visualization for years, and I’m interested in seeing what he’s up to here.
New Classes of Security and Privacy Vulnerabilities for Implantable Wireless Medical Devices — Tadayoshi Kohno, Kevin Fu
Remember when every juice was being mixed with Cranberry — CranApple, CranGrape, etc — because, oh man, people just can’t get enough of that Cran tang? RFID is the Cran of Technology.
Methods for Understanding Targeted Attacks with Office Documents — Bruce Dang
Bruce Dang is a badass. You people don’t even know.
Encoded, Layered, and Trancoded Syntax Attacks: Threading the Needle past Web Application Security Controls — Arian Evans
If you have no idea how redonkulous securely filtering content really needs to be, you need to see this talk.
Passive and Active Leakage of Secret Data from Non Networked Computer – Eric Filiol
Tempest v. Web 2.0 — two technologies enter, one technology leaves – with the data.
Get Rich or Die Trying - “Making Money on The Web, The Black Hat Way” — Jeremiah Grossman, Arian Evans
It’s 2008, and seriously, it’s all about monetization. Good to see a talk that recognizes that.
Reverse DNS Tunneling Shellcode — Ty Miller
So, anyone monitoring for DNS exfiltration yet? Anyone?
REST for the Wicked — Bryan Sullivan
Seriously? Is it possible to do REST securely?
Leveraging the Edge: Abusing SSL VPNs — Mike Zusman
You’ll see.
That’s enough for now. I’ll post in a bit on a few more things — there’s some really interesting Defcon-only talks this year, including a brings-tears-to-your-eyes-it-so-old-school stunt by Jonathan Brossard. And who knows, maybe I’ll even point out the talks I’d go see at SIGGRAPH if I could.
Well, it’s either that or do more work on DNS
